Item Code |
Rigid conductor section[mm²] | Rigid conductor section[AWG/MCM] | Flexible conductor section[mm²] | Flexible conductor section[AWG/MCM] | For screwØ screw[mm] | For screwStud size | Indent | W1[mm] | L1[mm] | L2[mm] | L3[mm] | L4[mm] | D1[mm] | D2[mm] | D3[mm] | For class conductors | Crimping | | Quantity per Wishlist |
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
011071• | 1.5 | (16) | 1.5 | (16) | 3 | #4 | - | 8 | 16 | 5 | 5 | 4 | 3,5 | 1,9 | 3,2 | - | 100/1000 | ||
011191• | 1.5 | (16) | 1.5 | (16) | 4 | #8 | - | 8 | 16 | 5 | 5 | 4 | 3,5 | 1,9 | 4,2 | - | 100/1000 | ||
011251• | 1.5 | (16) | 1.5 | (16) | 5 | #10 | - | 8 | 16 | 5 | 5 | 4 | 3,5 | 1,9 | 5,2 | - | 100/1000 | ||
011311• | 1.5 | (16) | 1.5 | (16) | 6 | #12 | - | 10 | 18 | 5 | 6 | 5 | 3,5 | 1,9 | 6,3 | - | 100/1000 | ||
012191• | 2.5 | (14) | 2.5 | (14) | 4 | #8 | - | 8 | 18 | 7 | 5 | 4 | 4 | 2,4 | 4,2 | - | 100/1000 | ||
012251• | 2.5 | (14) | 2.5 | (14) | 5 | #10 | - | 10 | 20 | 7 | 6 | 5 | 4 | 2,4 | 5,2 | - | 100/1000 | ||
012311• | 2.5 | (14) | 2.5 | (14) | 6 | #12 | - | 10 | 20 | 7 | 6 | 5 | 4 | 2,4 | 6,3 | - | 100/1000 | ||
013190• | 4 | (12) | 4 | (12) | 4 | #8 | - | 10 | 20 | 7 | 6 | 5 | 5,1 | 3,1 | 4,2 | - | 100/1000 | ||
013250• | 4 | (12) | 4 | (12) | 5 | #10 | - | 10 | 20 | 7 | 6 | 5 | 5,1 | 3,1 | 5,2 | - | 100/1000 | ||
013310• | 4 | (12) | 4 | (12) | 6 | #12 | - | 10 | 20 | 7 | 6 | 5 | 5,1 | 3,1 | 6,3 | - | 100/1000 | ||
013370• | 4 | (12) | 4 | (12) | 8 | 5/16" | - | 11 | 24 | 7 | 8,5 | 6,5 | 5,1 | 3,1 | 8,2 | - | 100/1000 | ||
013191• | 6 | (10) | 6 | (10) | 4 | #8 | - | 10 | 23 | 9 | 6 | 5 | 5,5 | 3,5 | 4,2 | - | 100/1000 | ||
013251• | 6 | (10) | 6 | (10) | 5 | #10 | - | 10 | 23 | 9 | 6 | 5 | 5,5 | 3,5 | 5,2 | - | 100/1000 | ||
013311• | 6 | (10) | 6 | (10) | 6 | #12 | - | 10 | 23 | 9 | 6 | 5 | 5,5 | 3,5 | 6,3 | - | 100/1000 | ||
013371• | 6 | (10) | 6 | (10) | 8 | 5/16" | - | 12 | 27 | 9 | 9 | 6 | 5,5 | 3,5 | 8,2 | - | 100/1000 | ||
013431• | 6 | (10) | 6 | (10) | 10 | 3/8" | - | 15 | 32 | 9 | 11 | 9 | 5,5 | 3,5 | 10,2 | - | 100/1000 | ||
01419* | 10 | (8) | 10 | (8) | 5 | #10 | 7 | 10 | 26,5 | 9,5 | 6,3 | 5 | 7 | 5 | 5,2 | 1, 2, 5, 6 | - | 100/100 | |
01431* | 10 | (8) | 10 | (8) | 6 | #12 | 7 | 11 | 28 | 9,5 | 6,5 | 5,5 | 7 | 5 | 6,3 | 1, 2, 5, 6 | - | 100/100 | |
01437* | 10 | (8) | 10 | (8) | 8 | 5/16" | 7 | 13,6 | 31,5 | 9,5 | 8,8 | 6,2 | 7 | 5 | 8,5 | 1, 2, 5, 6 | - | 100/100 | |
01443* | 10 | (8) | 10 | (8) | 10 | 3/8" | 7 | 17,2 | 34 | 9,5 | 9,6 | 9,5 | 7 | 5 | 10,5 | 1, 2, 5, 6 | - | 100/100 | |
01449* | 10 | (8) | 10 | (8) | 12 | 1/2" | 7 | 17 | 34,1 | 9,5 | 9,3 | 9,3 | 7 | 5 | 12,2 | 1, 2, 5, 6 | - | 100/100 | |
01525 | 16 | (6) | 16 | (6) | 5 | #10 | 7,5 | 11,5 | 30,5 | 11 | 8,7 | 6,3 | 8 | 6 | 5,3 | 1, 2, 5, 6 | - | 100/100 | |
01531 | 16 | (6) | 16 | (6) | 6 | #12 | 7,5 | 11,5 | 31 | 11 | 8,5 | 6 | 8 | 6 | 6,5 | 1, 2, 5, 6 | - | 100/100 | |
01537 | 16 | (6) | 16 | (6) | 8 | 5/16" | 7,5 | 15 | 36 | 12 | 9 | 8 | 8 | 6 | 8,5 | 1, 2, 5, 6 | - | 100/100 | |
01543 | 16 | (6) | 16 | (6) | 10 | 3/8" | 7,5 | 15 | 38,5 | 12 | 10,5 | 10 | 8 | 6 | 10,5 | 1, 2, 5, 6 | - | 100/100 | |
01549 | 16 | (6) | 16 | (6) | 12 | 1/2" | 7,5 | 16,5 | 39 | 12 | 10,5 | 10 | 8 | 6 | 13 | 1, 2, 5, 6 | - | 100/100 | |
01625 | 25 | (4) | 25 | (4) | 5 | #10 | 9 | 14 | 35,5 | 13,5 | 10 | 7 | 9,5 | 7 | 5,2 | 1, 2, 5, 6 | - | 100/100 | |
01631 | 25 | (4) | 25 | (4) | 6 | #12 | 9 | 14 | 35,5 | 13,5 | 10 | 7 | 9,5 | 7 | 6,3 | 1, 2, 5, 6 | - | 100/100 | |
01637 | 25 | (4) | 25 | (4) | 8 | 5/16" | 9 | 14 | 35,5 | 13,5 | 10 | 8 | 9,5 | 7 | 8,4 | 1, 2, 5, 6 | - | 100/100 | |
01643 | 25 | (4) | 25 | (4) | 10 | 3/8" | 9 | 17 | 39,5 | 14 | 10,5 | 9,5 | 9,5 | 7 | 10,5 | 1, 2, 5, 6 | - | 100/100 | |
01649 | 25 | (4) | 25 | (4) | 12 | 1/2" | 9 | 18,5 | 39,5 | 14 | 11 | 9,5 | 9,5 | 7 | 13 | 1, 2, 5, 6 | - | 100/100 | |
01731 | 35 | (2) | 35 | (2) | 6 | #12 | 11 | 17 | 37 | 15 | 9,5 | 6 | 11,5 | 8,5 | 6,4 | 1, 2, 5 | 100/100 | ||
01737 | 35 | (2) | 35 | (2) | 8 | 5/16" | 11 | 17 | 41,5 | 15 | 10,5 | 10 | 11,5 | 8,5 | 8,5 | 1, 2, 5 | 100/100 | ||
01743 | 35 | (2) | 35 | (2) | 10 | 3/8" | 11 | 17 | 45 | 15 | 12 | 9,5 | 11,5 | 8,5 | 10,5 | 1, 2, 5 | 100/100 | ||
01749 | 35 | (2) | 35 | (2) | 12 | 1/2" | 11 | 20 | 46 | 15 | 14 | 11,5 | 11,5 | 8,5 | 13 | 1, 2, 5 | 100/100 | ||
01831 | 50 | (1/0) | 50 | (1/0) | 6 | #12 | 12 | 18,7 | 45,5 | 18 | 9 | 9 | 13 | 10 | 6,4 | 1, 2, 5 | 100/100 | ||
01837 | 50 | (1/0) | 50 | (1/0) | 8 | 5/16" | 12 | 18,7 | 47,5 | 18 | 10 | 10 | 13 | 10 | 8,4 | 1, 2, 5 | 100/100 | ||
01843 | 50 | (1/0) | 50 | (1/0) | 10 | 3/8" | 12 | 18,7 | 49,5 | 18 | 11 | 11 | 13 | 10 | 10,5 | 1, 2, 5 | 100/100 | ||
01849 | 50 | (1/0) | 50 | (1/0) | 12 | 1/2" | 12 | 21 | 53 | 18 | 15,3 | 12 | 13 | 10 | 12,5 | 1, 2, 5 | 100/100 | ||
01855 | 50 | (1/0) | 50 | (1/0) | 14 | 9/16" | 12 | 22 | 53 | 17 | 15,3 | 12 | 13 | 10 | 14,5 | 1, 2, 5 | 100/100 | ||
01931• | 70 | (2/0) | 70 | (2/0) | 6 | #12 | 14 | 21,8 | 51 | 20,5 | 11 | 10 | 15 | 12 | 6,5 | 1, 2, 5 | 100/100 | ||
01937• | 70 | (2/0) | 70 | (2/0) | 8 | 5/16" | 14 | 21,8 | 51 | 20,5 | 11 | 10 | 15 | 12 | 8,5 | 1, 2, 5 | 100/100 | ||
01943• | 70 | (2/0) | 70 | (2/0) | 10 | 3/8" | 14 | 21,8 | 57 | 20,5 | 14,5 | 11,2 | 15 | 12 | 10,5 | 1, 2, 5 | 100/100 | ||
01949• | 70 | (2/0) | 70 | (2/0) | 12 | 1/2" | 14 | 22 | 57 | 20,5 | 13 | 13 | 15 | 12 | 12,5 | 1, 2, 5 | 100/100 | ||
01955• | 70 | (2/0) | 70 | (2/0) | 14 | 9/16" | 14 | 22 | 57 | 20,5 | 14 | 11,3 | 15 | 12 | 14,5 | 1, 2, 5 | 100/100 | ||
01961• | 70 | (2/0) | 70 | (2/0) | 16 | 5/8" | 14 | 22 | 57 | 20,5 | 14 | 11,3 | 15 | 12 | 16,5 | 1, 2, 5 | 100/100 | ||
03137• | 95 | (3/0) | 95 | (3/0) | 8 | 5/16" | 16 | 25 | 54,5 | 23,5 | 9 | 8 | 17,5 | 13,8 | 8,5 | 1, 2, 5 | 50/50 | ||
03143• | 95 | (3/0) | 95 | (3/0) | 10 | 3/8" | 16 | 25 | 60 | 23 | 12,5 | 12,5 | 17,5 | 13,8 | 10,5 | 1, 2, 5 | 50/50 | ||
03149• | 95 | (3/0) | 95 | (3/0) | 12 | 1/2" | 16 | 25 | 62 | 23 | 14 | 13 | 17,5 | 13,8 | 12,5 | 1, 2, 5 | 50/50 | ||
03155• | 95 | (3/0) | 95 | (3/0) | 14 | 9/16" | 16 | 25 | 65 | 23 | 17 | 13 | 17,5 | 13,8 | 14,5 | 1, 2, 5 | 50/50 | ||
03161• | 95 | (3/0) | 95 | (3/0) | 16 | 5/8" | 16 | 25 | 65 | 23 | 17 | 13,5 | 17,5 | 13,8 | 16,5 | 1, 2, 5 | 50/50 | ||
03237 | 120 | (4/0) | 120 | (4/0) | 8 | 5/16" | 18 | 28 | 64 | 25 | 14 | 14 | 19,5 | 15,5 | 8,5 | 1, 2, 5 | 50/50 | ||
03243 | 120 | (4/0) | 120 | (4/0) | 10 | 3/8" | 18 | 28 | 64 | 25 | 14 | 14 | 19,5 | 15,5 | 10,5 | 1, 2, 5 | 50/50 | ||
03249 | 120 | (4/0) | 120 | (4/0) | 12 | 1/2" | 18 | 28 | 64 | 25 | 14 | 14 | 19,5 | 15,5 | 12,5 | 1, 2, 5 | 50/50 | ||
03255 | 120 | (4/0) | 120 | (4/0) | 14 | 9/16" | 18 | 28 | 67 | 25 | 15 | 16 | 19,5 | 15,5 | 14,5 | 1, 2, 5 | 50/50 | ||
03261 | 120 | (4/0) | 120 | (4/0) | 16 | 5/8" | 18 | 28 | 70 | 25 | 15 | 16 | 19,5 | 15,5 | 16,5 | 1, 2, 5 | 50/50 | ||
03337 | 150 | (300) | 150 | (300) | 8 | 5/16" | 20 | 31 | 64 | 28 | 13 | 11 | 21 | 17 | 8,4 | 1, 2, 5 | 50/50 | ||
03343 | 150 | (300) | 150 | (300) | 10 | 3/8" | 20 | 31 | 64 | 28 | 13 | 11 | 21 | 17 | 10,4 | 1, 2, 5 | 50/50 | ||
03349 | 150 | (300) | 150 | (300) | 12 | 1/2" | 20 | 31 | 70 | 28 | 14 | 13 | 21 | 17 | 12,5 | 1, 2, 5 | 50/50 | ||
03355 | 150 | (300) | 150 | (300) | 14 | 9/16" | 20 | 31 | 70,5 | 28 | 15,5 | 15 | 21 | 17 | 14,5 | 1, 2, 5 | 50/50 | ||
03361 | 150 | (300) | 150 | (300) | 16 | 5/8" | 20 | 31 | 73 | 30 | 15 | 16 | 21 | 17 | 16,5 | 1, 2, 5 | 50/50 | ||
03367 | 150 | (300) | 150 | (300) | 20 | 3/4" | 20 | 31 | 73 | 30 | 22 | 16 | 21 | 17 | 21 | 1, 2, 5 | 50/50 | ||
03443 | 185 | (400) | 185 | (400) | 10 | 3/8" | 22 | 35 | 75 | 30 | 16 | 14 | 24 | 19 | 10,5 | 1, 2, 5 | 50/50 | ||
03449 | 185 | (400) | 185 | (400) | 12 | 1/2" | 22 | 35 | 75 | 30 | 16 | 14 | 24 | 19 | 13 | 1, 2, 5 | 50/50 | ||
03455 | 185 | (400) | 185 | (400) | 14 | 9/16" | 22 | 35 | 79 | 30 | 18 | 16 | 24 | 19 | 15 | 1, 2, 5 | 50/50 | ||
03461 | 185 | (400) | 185 | (400) | 16 | 5/8" | 22 | 35 | 81 | 30 | 19 | 17 | 24 | 19 | 17 | 1, 2, 5 | 50/50 | ||
03467 | 185 | (400) | 185 | (400) | 20 | 3/4" | 22 | 35 | 87 | 30 | 22 | 20 | 24 | 19 | 21 | 1, 2, 5 | 50/50 | ||
03543• | 240 | (500) | 240 | (500) | 10 | 3/8" | 25 | 39,5 | 81 | 35 | 16 | 14 | 27 | 21,5 | 10,5 | 1, 2, 5 | 50/50 | ||
03549 | 240 | (500) | 240 | (500) | 12 | 1/2" | 25 | 39,5 | 81 | 35 | 16 | 14 | 27 | 21,5 | 13 | 1, 2, 5 | 50/50 | ||
03555 | 240 | (500) | 240 | (500) | 14 | 9/16" | 25 | 39,5 | 85 | 35 | 18 | 16 | 27 | 21,5 | 15 | 1, 2, 5 | 50/50 | ||
03561 | 240 | (500) | 240 | (500) | 16 | 5/8" | 25 | 39,5 | 87 | 35 | 19 | 17 | 27 | 21,5 | 17 | 1, 2, 5 | 50/50 | ||
03567 | 240 | (500) | 240 | (500) | 20 | 3/4" | 25 | 39,5 | 93 | 35 | 22 | 20 | 27 | 21,5 | 21 | 1, 2, 5 | 50/50 | ||
03649 | 300 | (600) | 300 | (600) | 12 | 1/2" | 28 | 44 | 101 | 38 | 22 | 20 | 30 | 24 | 13 | 1, 2, 5 | 25/25 | ||
03655 | 300 | (600) | 300 | (600) | 14 | 9/16" | 28 | 44 | 101 | 38 | 22 | 20 | 30 | 24 | 15 | 1, 2, 5 | 25/25 | ||
03661 | 300 | (600) | 300 | (600) | 16 | 5/8" | 28 | 44 | 101 | 38 | 22 | 20 | 30 | 24 | 17 | 1, 2, 5 | 25/25 | ||
03667 | 300 | (600) | 300 | (600) | 20 | 3/4" | 28 | 44 | 101 | 38 | 22 | 20 | 30 | 24 | 21 | 1, 2, 5 | 25/25 | ||
03669• | 300 | (600) | 300 | (600) | 24 | 15/16" | 28 | 44 | 101 | 38 | 22 | 20 | 30 | 24 | 25 | 1, 2, 5 | 25/25 | ||
03749• | 400 | (800) | 300 | (600) | 12 | 1/2" | 35 | 50 | 108 | 40 | 22 | 20 | 35 | 27 | 13 | 1, 2, 5 | 10/10 | ||
03755• | 400 | (800) | 300 | (600) | 14 | 9/16" | 35 | 50 | 108 | 40 | 22 | 20 | 35 | 27 | 15 | 1, 2, 5 | 10/10 | ||
03761• | 400 | (800) | 300 | (600) | 16 | 5/8" | 35 | 50 | 108 | 40 | 22 | 20 | 35 | 27 | 17 | 1, 2, 5 | 10/10 | ||
03767• | 400 | (800) | 300 | (600) | 20 | 3/4" | 35 | 50 | 108 | 40 | 22 | 20 | 35 | 27 | 21 | 1, 2, 5 | 10/10 | ||
03769• | 400 | (800) | 300 | (600) | 24 | 15/16" | 35 | 50 | 108 | 40 | 22 | 20 | 35 | 27 | 25 | 1, 2, 5 | 10/10 | ||
03861• | 500 | (1000) | 400 | (800) | 16 | 5/8" | 38 | 55 | 124 | 51 | 25 | 23 | 38 | 30 | 17 | 1, 2, 5 | 5/5 | ||
03867• | 500 | (1000) | 400 | (800) | 20 | 3/4" | 38 | 55 | 124 | 51 | 25 | 23 | 38 | 30 | 21 | 1, 2, 5 | 5/5 | ||
03961• | 630 | (1250) | 500 | (1000) | 16 | 5/8" | 42 | 61 | 131 | 58 | 25 | 23 | 42 | 33,6 | 17 | 1, 2, 5 | 5/5 | ||
03967• | 630 | (1250) | 500 | (1000) | 20 | 3/4" | 42 | 61 | 131 | 58 | 25 | 23 | 42 | 33,6 | 21 | 1, 2, 5 | 5/10 |
