PDF documents
Images with
dimensions
dimensions
| Item Code |
Section[mm²] | Cable diameter[mm] | For screwØ screw[mm] | For screwStud size | D1[mm] | Screw | D2[mm] | W1[mm] | L1[mm] | L2[mm] | L3[mm] | | Quantity per Wishlist |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 5160 | 4 ÷ 10 | 2 ÷ 4 | 5 | #10 | 4,2 | M5 | 5,25 | 12 | 26,5 | 12 | 7 | 100/100 | |
| 5161 | 10 ÷ 25 | 4 ÷ 6 | 5 | #10 | 6,2 | M6 | 6 | 14 | 36 | 11 | 8 | 100/100 | |
| 5162 | 25 ÷ 35 | 6 ÷ 8,5 | 5 | #10 | 8,5 | M7 | 6 | 17 | 38 | 12,5 | 8 | 100/100 | |
| 5163 | 35 ÷ 50 | 8,5 ÷ 11 | 7 | 9/32" | 11,5 | M10 | 8,3 | 23 | 50 | 18 | 12 | 50/50 | |
| 5164 | 70 ÷ 95 | 11 ÷ 14 | 10 | 3/8" | 15 | M12 | 10,5 | 26,5 | 55 | 20,5 | 14,5 | 25/25 | |
| 5165 | 95 ÷ 120 | 14 ÷ 17 | 10 | 3/8" | 27,5 | M14 | 11,5 | 32 | 64 | 23 | 16 | 25/25 | |
| 5167 | 185 ÷ 240 | 20,5 ÷ 24 | 16 | 5/8" | 24 | M16 | 17 | 40 | 94 | 31,5 | 23 | 10/20 |
