| Item Code |
Section[mm²] | For screwØ screw[mm] | For screwStud size | D1[mm] | Screw | D2[mm] | W1[mm] | L1[mm] | | Quantity per Wishlist |
|---|---|---|---|---|---|---|---|---|---|---|
| 5144 | 50 | 10 | 3/8" | 9,5 | M6 | 10,5 | 23 | 56,5 | 100/100 | |
| 5145 | 75 | 12 | 1/2" | 11 | M6 | 13,25 | 26 | 61 | 50/50 | |
| 5146 | 100 | 12 | 1/2" | 13 | M6 | 14,3 | 29 | 65 | 50/50 | |
| 5147 | 120 | 14 | 9/16" | 14 | M6 | 14,8 | 32 | 71 | 50/50 | |
| 5148 | 170 | 14 | 9/16" | 16 | M8 | 16 | 33 | 81 | 25/25 | |
| 5150 | 250 | 16 | 5/8" | 18 | M8 | 17 | 38 | 87,5 | 20/20 | |
| 5151 | 300 | 18 | 13/16" | 21 | M10 | 19,8 | 45 | 118 | 15/15 | |
| 5152 | 400 ÷ 500 | 22 | 7/8" | 25,5 | M10 | 22 | 53 | 132 | 10/10 | |
| 5153 | 700 | 22 | 7/8" | 34 | M10 | 22 | 60 | 150 | 1/1 |
